Investigación







Surface Modes in NWs















Nanowires are structures with an elongated shape and a large surface to volume ratio.

This results in the appearance of atomic vibrational modes specifically related to the

oscillation of surface atoms. Surface optical modes (SO) are characteristic vibrations of the

free surface of polar semiconductors. This means that their amplitude is maximum at the

surface and decays exponentially away from it. Therefore they are very sensitive to

changes that take place at the surface of the materials: dielectric environment, specific

morphology of the surface, adsorbates etc.



We have investigated the dependence of the frequency of the surface modes as a function

of NW density and NW environment:



                                    R. Mata et al. Phys. Rev. B 85, 035322 (2012)



The Raman spectra were obtained from locations of the sample with different NW density.

Its frequency decreases as both density and diameter of the wires decrease.

By means of macroscopic models we have analyzed the influence of NW size and density on

the surface modes.



In the theoretical approach the density of the nanowires is given through the filling factor F (proportion of material with respect to surrounding air). It is shown that NWs are well

described as “isolated” for F<0.4, while larger filling factors are better described by the

Maxwell-Garnett approximation, that takes into account NW-NW interaction through an

effective-dielectric function of NWs and air.



The theoretical results indicate that under certain conditions (F≈0.4, incident angle≠0) it is possible to observe the anticrossing of two SO modes. The frequency of these modes shifts when we change the dielectric properties of the environment (change air by paraffin oil). The

changes can be appreciated in the figure below (left, experimental results. Right,

calculated spectra).





                      J. Wang et. al. Phys. Rev. B 85, 155432 , (2012)





The relative intensities of S1 and S2 are very sensitive to NW density and scattering angle.

This last figure gives an idea of the variation of the frequency and intensity of the modes.

The size of the symbols is proportional to the intensity of the Raman peak.
